Description
Replacement COM12T bearing
Used in the GT86-DTOP only.
COM12T
| IMPERIAL | METRIC |
|---|---|
| HOUSING OUTER DIAMTER | HOUSING OUTER DIAMTER |
| 1.438 in | 36.5 mm |
| HOUSING WIDTH | HOUSING WIDTH |
| 0.593 in | 15.1 mm |
| BALL WIDTH | BALL WIDTH |
| 0.75 in | 19.05 mm |
| BALL BORE SIZE | BALL BORE SIZE |
| 1.187 in | 30.1 mm |
| BEARING MISALIGNMENT ANGLE | BEARING MISALIGNMENT ANGLE |
| 9 degrees | 9 degrees |
| ULT. Static Radial Load (lbs) | ULT. Static Radial Load (kg) |
| 47,880 lbs | 21,718 kg |
| BEARING MATERIAL | BEARING MATERIAL |
| STEEL | STEEL |
| LUBRICATION | LUBRICATION |
| PTFE lined | PTFE lined |
