Comp Cams 54-470-11 Lsr Hydraulic Roller Camshaft For Ls Engines

Description

Brand: COMP Cams
Manufacturer’s Part Number: 54-470-11
Part Type: Camshafts
Product Line: COMP Cams LSR Series Hydraulic Roller Camshafts
Automotive Fittings Part Number: CCA-54-470-11
UPC: 036584195320
Cam Style: Hydraulic roller, OE roller
Camshaft Use: Street/Strip
Basic Operating RPM Range: 2,200-7,200
Intake Duration at 050 inch Lift: 235
Exhaust Duration at 050 inch Lift: 251
Duration at 050 inch Lift: 235 int./251 exh.
Advertised Intake Duration: 285
Advertised Exhaust Duration: 301
Advertised Duration: 285 int./301 exh.
Intake Valve Lift with Factory Rocker Arm Ratio: 0.621 in.
Exhaust Valve Lift with Factory Rocker Arm Ratio: 0.624 in.
Valve Lift with Factory Rocker Arm Ratio: 0.621 int./0.624 exh.
Lobe Separation (degrees): 113
Camshaft Gear Attachment: 3-bolt
Remanufactured: No
Computer-Controlled Compatible: Yes
Grind Number: 285LRRHR13
Valve Springs Required: Yes
Quantity: Sold individually.
Notes: Cannot use stock springs. With rectangular port heads. Custom computer tuning required.
Description:
COMP Cams LSR Series hydraulic roller camshafts feature modern lobe profiles that take full advantage of high-flowing late model GM LS3 rectangular port cylinder heads. They are tailored for a specific rpm range and usage, from torque to high-rpm horsepower. Give your Chevy LS3 engine a shot in the arm with one of these COMP Cams LSR Series hydraulic roller camshafts.
