Je Pistons 232456 — Forged Inverted-Dome 440 Cubic Inch Engine Pistons For Max Compression

Description

Brand: JE Pistons
Manufacturer’s Part Number: 232456
Part Type: Pistons
Product Line: JE Pistons 440 Inverted Dome Top Pistons
Automotive Fittings Part Number: JEP-232456-8
UPC: 193564047380
Piston Rings Included: No
Bore (in.): 4.350 in.
Bore (mm): 110.490mm
Stroke: 3.750 in.
Engine Stroke Type: Stock
Rod Length: 6.766 in.
Piston Style: Dish, with two valve reliefs
Piston Material: Forged aluminum
Compression Height (in.): 2.058 in.
Piston Head Volume (cc): +18.10cc
Wrist Pin Style: Press-fit or floating
Wrist Pin Retainers Included: Yes
Wrist Pin Included: Yes
Pin Diameter (in.): 0.990 in.
Piston Ring Thickness: 1/16 in. x 1/16 in. x 3/16 in.
File Fit: No
Gapless: No
Remanufactured: No
Quantity: Sold as a set of 8.
Description:
These JE Pistons 440 inverted dome top pistons are designed for high performance street/strip applications and are compatible with nitrous and forced induction systems. They are machined to accept 1/16, 1/16, 3/16 rings and come available in either .990 in. or 1.094 in. wrist pin diameters. For other specific applications, please check with the manufacturer.
