Description
Python NV/L 20 green multipurpose hose is designed to respond with an efficient and efficacious solution to the majority of industrial applications, including those with an heavy duty mission profile.
Parker IH30351/40 Python NV 20
TECHNICAL CHARACTERISTICS
|
Burst Pressure min |
60 bar |
|
Working pressure max. (bar) |
20 bar |
|
Working pressure max. (PSI) |
300 PSI |
|
Bend Radius min. |
60 mm |
|
O.D. |
17 mm |
|
Inner diameter 1 |
10 mm |
|
Weight |
0.22 kg/m |
|
Hose O.D. 1 |
17 mm |
|
Hose I.D. 1 |
10 mm |
|
Temp. max. |
120 °C |
|
Temp. min. |
-40 °C |
|
Part Number |
Quantity |
Price |
| IH30351200/40 | 40 | $ 16.36 |
|
IH30351201/40 |
40 |
$ 19.02 |
|
IH30351202/40 |
40 |
$ 22.45 |
|
IH30351203/40 |
40 |
$ 28.38 |
|
IH30351204/40 |
40 |
$ 39.13 |
WARNING: This product can expose you to chemicals including Carbon black (airborne, unbound particle which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
