Description
The main function of port reducers is to match the sizes of different ports. This range of port reducers is available in steel with Cr(VI)-free surfaces and stainless steel.
TECHNICAL CHARACTERISTICS
| Shape | Thread reducer/expander |
| Connection Size | G 1 1/4 A |
| Connection Size 2 | G 1 |
| Connection 1 Style | Male BSPP thread – ED-seal (ISO 1179) |
| Connection 2 Style | Female BSPP thread (ISO 1179-1) |
| Material | Steel, Chromium-6 Free |
| Industry Standards |
DIN ISO 8434 |
| Tube O.D (mm) |
6-42 |
| Working Temperature (C) |
-40 to +250 Steel, -60 to +400 Stainless Steel |
| Working Temperature (F) |
-40 to +482 Steel, -76 to +752 Stainless Steel |
| Working Pressure (bar) |
160-400 |
| Working Pressure (mpa) | 16-40 |
| Working Pressure (psi) |
2321-5802 |
| Connection Type |
Bite Type, Soft Seal Bite Type |
| Application |
Agriculture Equipment, Automotive Process, Chemical Transfer, Construction Equipment, Fuel transfer, Hydraulic, Manufacturing Equipment, Marine, Material Handling, Mobile Equipment, Oilfield, Packaging, Transportation |
| Weight | 1.12 |
| PART NUMBER | QUANTITY | PRICE |
| RI11/2EDX1CF | 5 | $13.73 |
| RI11/4EDX1CF | 4 | $11.82 |
| RI11/4EDX3/4CF | 4 | $9.31 |
